LW300FV small loader for sale | XCMG LW300FV 3ton wheel loader price
$20000.00-$30000.00
1 / EA (Min. Order)
Payment
Shipping
Support Sea freight · Land freight · Air freight
XCMG E-commerce Inc.
Follow
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
Recommendation
Summary
Rated Load: 3 ton
Dimension(Long* Breadth * High): 7245*2482*3050mm
Type: wheel loader
Place of Origin: Xuzhou, China
Model Number: LW300FV
Brand Name: XCMG
Certification: ISO

XCMG 3ton wheel loader LW300FV.



XCMG wheel loader LW300FV is the most popular model of 3ton China wheel loader, XCM LW300FV is  new model equipped with EURO III engine with electric injector, new model will have high performance.



LW300FV can be used for shoveling, transporting, unloading and leveling. If the corresponding working device is replaced, it can also be used for bulldozing, lifting, loading and unloading wood and steel pipes. It is a kind of ten purposes. A wide range of construction machinery.



Performance Characteristics:

1, High energy-conservation, efficiency, reliability, and comfort.

2, All load-carrying portions of the drive axle are solid and firm enough to ensure excellent overload resistance and meet the needs of diversified high strength and high load operations.

3,  As the sole low speed engine energy-conservation product among the industry's 3t loaders, it’s leading the industry’s energy-conservation trend.

4, The full-view cab sufficiently takes in consideration the human-machine functions to realize high operation safety and comfort.

5, Undertaking the concept of “ground maintenance”, all maintenance locations are scientifically arranged to ease the checking and maintenance.



LW300FV optional parts:

A/C/ 1.8m3 Blade bucket/ 2.1m3 Lignt material Blade bucket/ 2.5m3 Lignt material Blade bucket / 1.8m3 Reinforced bucket



Description

Specification

Unit

Rated operating load

3000

kg

Bucket capacity

1.8

m3

Machine weight

10600±200

kg

Dump clearance at maximum lift

2930

mm

Reach at maximum lift

1010

mm

Wheel base

2600

mm

Tread

1850

mm

Max. breakout force

130

Kn

Max. horse power

95

Kn

Total hydraulic cycle time

8.8

s

Min. turning radius over tyres

5165

mm

Articulation angle

35

°

Overall machine dimension LxWxH

7245x2482x3050-3210

mm

Engine Model

WP6G125E333



Rated power/Speed

92/2000

Kw/rpm









More About XCMG Wheel Loader
