XCMG official XE27U 3 ton small mini excavator
Developed with the concept of “Safe, Reliable, Efficient and Comfortable” , the XE27U hydraulic excavator offers additional value to the operator. New features are presented making the machines more productive,versatile, and cost effective.
* Kubota T4F engine D1105 , along with our load-sensing hydraulic system provides efficiency and fuel economy.
* This compact short-tail excavator is designed to perform a wide variety of tasks on the most challenging jobsites such as in demolition, landscaping, earthmoving or material handling. It gets the job done as you expected!
* Grouped service points are within reach from the ground, making maintenance easier and reducing your potential downtime.
Angle Boom
The left (75°) and right (55°) boom swing angles give the operator confidence and efficiency during complex operating conditions like parallel wall digging or travelling in narrow spaces.
Made for Easy Transportation
With a set of buckets, hammer and rubber track, the XE27U weighs less than 6 200 lb. And the accessible large tow rings make it easy to switch between your jobsites.
AUX1& 2 and Coupler Pipelines
With the multiple programmable 2-way proportional auxiliary lines and quick-coupler piping the XE27U meets almost all your attachment needs.
Boom, Arm Safety Valves and Standard Blade Holding Valve
The XE27U is equipped with standard boom cylinder safety valve, arm cylinder valve and a dozer holding valve to protect the operator as well as individuals around during operations.
Description | Parameter value |
Operating weight | 2780Kg |
Bucket capacity | 0.06m³ |
Engine | Model | Kubota/D1105 /EU Stage V |
| No. of cylinders | 3 |
| Output power | 15.4 kW (20.9 hp) / 2400 rpm |
| torque/speed | 70.3 N.m/1600 rpm |
| Displacement | 1123 cm³ |
Hydraulic system | Travel speed (low - high) | 2.2- 3.1km/h |
| Gradeability | 30° |
Oil Capacity | Fuel tank capacity | 33L |
| Hydraulic tank capacity | 22L |
| Engine oil capacity | 5.1L |
Working scope | Boom deflflection distance (left/right) | 610/585 mm |
| Max. digging height | 4390mm |
| Max. dumping height | 3120mm |
| Max. digging depth | 2800mm |
| Max. vertical wall digging depth | 2310mm |
| Max. digging radius | 4750mm |
| Min. swing radius | 1980mm |
