XCMG official XE15U New Mini excavators for sale
XE15U mini excavator uses a mechanical injection oil engine with national II emission standards and has characteristics of strong power, energy conservation and environmental protection, high reliability and excellent performance. With latest technological achievements used, key hydraulic parts have low energy consumption, fast response speeds, accurate control, and small impact forces, and can maintain strong mining ability and high operation efficiency.
Performance & Characteristic:
1. More efficient return
Tailless design for a turning radius ensures that the XE15U hydraulic excavator will not touch obstacles at the tail in narrow working conditions.
2. More reliable and durable
A four-point supporting shed that meets safety standards is used for the cab, and widens the driver's horizon while ensures the shed's strength. Seats are configured with standard safety belts, improving driver's working security.
3. More comfortable and safe
Brand-new designed hand holder, cup holder, etc. improve operation comfort and convenience maximally.
| Description | Unit | Parameter value |
| Operating weight | Kg | 1795 |
| Bucket capacity | m³ | 0.04 |
| Engine | Model | / | D782-E3B-CBH-1 |
| | No. of cylinders | / | 3 |
| | Output power | kw/rpm | 9.8/2300 |
| | torque/speed | N.m | 44.5/1800 |
| | Displacement | L | 0.778 |
| Hydraulic system | Travel speed(H/L) | km/h | 4.3/2.2 |
| | Gradeability | ° | 30° |
| | Pressure of prime valve | MPa | 22 |
| | Pressure of travel system | MPa | 22 |
| | Pressure of swing system | MPa | 11 |
| | Pressure of pilot system | MPa | 3.9 |
| Oil Capacity | Fuel tank capacity | L | 18 |
| | Hydraulic tank capacity | L | 17 |
| | Engine oil capacity | L | 3.8 |
| Appearance size | Overall length | mm | 3560 |
| | Overall width | mm | 1240 |
| | Overall height | mm | 2348 |
| | Width of platform | mm | 990 |
| | Overall width of chassis | mm | 990/1240 |
| | Width of crawler | mm | 230 |
| | Track length on ground | mm | 1270 |
| | Crawler gauge | mm | 760/1010 |
| | Clearance under counterweight | mm | 450 |
| | Min. ground clearance | mm | 145 |
| Working scope | Min. tail swing radius | mm | 620 |
| | Max. digging height | mm | 3475 |
| | Max. dumping height | mm | 2415 |
| | Max. digging depth | mm | 2290 |
| | Max. vertical wall digging depth | mm | 1750 |
| | Max. digging reach | mm | 3900 |
| | Min. swing radius | mm | 1530 |
| Standard | Length of boom | mm | 1690 |
| | Length of arm | mm | 1100 |
| | Bucket capacity | m³ | 0.04 |
