XVB38-QL8-C
Specs & Compare
Details
Select 3 models for comparison
Fork Width
Fork Length
Min Lifting Height
Max Lifting Height
Rated Loading Capacity
Power Source
Type
Model Number
Brand Name
Place of Origin
Storage & Logistics Equipment
XVB38-QL8-C
1450 mm
3075 mm
--
3000mm
3.8t
Electricity
balance forklift
XVB38-QL8-C
XCMG
Xuzhou, Jiangsu, China
+ Add a Product
+ Add a Product
Summary
- Fork Width:1450 mm
- Fork Length:3075 mm
- Max Lifting Height:3000mm
- Rated Loading Capacity:3.8t
- Power Source:Electricity
- Type:balance forklift
- Model Number:XVB38-QL8-C
- Brand Name:XCMG
- Place of Origin:Xuzhou, Jiangsu, China
Specifications
- weight:38000.000kg
- Model:XVB38-QL8-C
- Rated Lifting Capacity:3800 kg
Basic Parameters
|
Parameter
|
Specification
|
|---|---|
|
Model
|
XVB38-QL8-C
|
|
Rated Load Capacity
|
3800 kg
|
|
Load Center
|
500 mm
|
|
Maximum Travel Speed (loaded)
|
20 km/h
|
|
Maximum Travel Speed (unloaded)
|
22 km/h
|
|
Lifting Speed (loaded)
|
480 mm/s
|
|
Lifting Speed (unloaded)
|
520 mm/s
|
|
Lowering Speed (loaded)
|
≤ 600 mm/s
|
|
Gradability (loaded)
|
≥ 20%
|
|
Overall Length (without fork)
|
3075 mm
|
|
Overall Width
|
1450 mm
|
|
Turning Radius
|
2450 mm
|
|
Total Weight (including battery)
|
Approx. 5200 kg
|
Configuration
-
160V High-Voltage Permanent Magnet Synchronous System
-
IPX5 Vehicle-Water Protection
-
Liquid Cooling for the Three Electric Systems (Battery, Motor, Control)
-
2-Spool Valve
-
2-Stage Mast, 3m Lifting Height
-
1070mm Fork Length
-
Full Pneumatic Tires
-
Battery Heating (Standard)
-
1C Fast Charging Support
