Summary
- Rated Power:420kw
- Model Number:XLZ230K
- Place of Origin:Jiangsu,China
- Rated Speed:0~2.4km/h
- Paving Width:2300mm
- Paving Thickness:450mm
Specifications
- weight:34000.000kg
- Condition:New
- Moving Type:Other
XCMG Official New Road Machinery XLZ230K Road Cold Recycler.
XLZ230K road cold recycler is efficient, reliable and compact. Reasonable layout of tool bits facilitates high milling ability; Intelligent control of sprinkler system provides easy operation and high spraying precision; All wheel steering is flexible and easy to operate; The three-power curve of the engine realizes working in multiple working conditions, such as heavy load, light load and transitions, effectively guarantees the efficient operation of the engine, energy saving and environmental friendly.
1.With XCMG's rotor technology, reasonable design and high milling accuracy.
2.The traveling system includes two speed modes, namely high speed mode and low.
3.The steering system incorporates the crabwalk function.
4.The engine includes advanced functions, including online display, malfunction diagnosis, and malfunction warning.
5.The pneumatic brake system is applied to realize the service braking and parking brake functions of the machine.
6.The cab is in wide-body structure and to realize comfortable operations.
|
Milling width |
2300 mm |
|
Maximum milling depth |
450 mm |
|
Tool spacing |
30×2 mm |
|
Number of tools |
200/141 |
|
Milling wheel diameter (with tool) |
1480 mm |
|
Manufacturer |
MTU |
|
Cooling method |
water cooling |
|
Model |
OM502LA.E3A/3 |
|
Number of cylinders |
8 |
|
Rated power |
420kw |
|
Engine speed |
1800 rpm |
|
Fuel consumption: full load |
90.3 kg/h |
|
Working speed |
0-2.4 km/h |
|
Walking speed |
0-10km/h |
|
Theoretical Gradeability (Work Block) |
50% |
|
Ground clearance |
350 |
|
Front axle load |
20000kg |
|
Rear axle load |
14000kg |
|
Shipping weight |
34000kg |
|
Fuel tank |
1200L |
|
Hydraulic tank |
400L |
|
Water tank |
400L |
|
Electrical system |
24V |
|
Machinery (length×width×height) |
9390×2995×3484mm |
