Specs & Compare
Details
Select 3 models for comparison
Rated Load
Dimension(Long* Breadth * High)
Type
Place of Origin
Model Number
Brand Name
Certification
Engineering & Construction Machinery
3000kg
7245x2482x3210mm
--
China
LW200KV
XCMG
IOS9001
+ Add a Product
+ Add a Product
Summary
- Rated Load:3000kg
- Dimension(Long* Breadth * High):7245x2482x3210mm
- Place of Origin:China
- Model Number:LW200KV
- Brand Name:XCMG
- Certification:IOS9001
Specifications
- weight:10800.000kg
- Condition:New
- Moving Type:Wheel
Description |
Specification |
Unit |
|
Rated operating load |
3000 |
kg |
|
Bucket capacity |
1.8 |
m³ |
|
Machine weight |
10800±200 |
kg |
|
Dump clearance at maximum lift |
2930 |
mm |
|
Reach at maximum lift |
1010 |
mm |
|
Wheel base |
2900 |
mm |
|
Tread |
1850 |
mm |
|
Max. breakout force |
130 |
Kn |
|
Max. horse power |
95 |
Kn |
|
Hydraulic cycle time-raise |
4.5 |
s |
|
Total hydraulic cycle time |
8.8 |
s |
|
| |||
Min. turning radius over tyres |
5170 |
mm |
|
Articulation angle |
35 |
° |
|
Gradeability |
28 |
° |
|
Tyre size |
17.5-25-12PR |
||
Overall machine dimension LxWxH |
7245x2482x3050-3210 |
mm |
|
Engine Model |
WP6G125E333 |
||
Rated power/Speed |
92/2000 |
Kw/rpm |
|
Travel speed |
I-gear(F/R) |
12/16 |
km/h |
II-gear(F/R) |
38 |
km/h |
