Summary
- Dimension(Long * Breadth * High):7616*3500*3402mm
- Machine Weight:23800kg
- Model Number:SD7N
- Brand Name:XCMG
- Place of Origin:Xuhzou, China
Specifications
- weight:23800.000kg
- Condition:New
- Moving Type:Crawler
- Engine:Cummins/ Weichai
- Dozing capacity:8.4m3
XCMG 230hp Triangle Type Bulldozer with Three Shanks Ripper SD7N.
XCMG triangle type bulldozer SD7N integrate with modular design is easy to repair& maintenance, It relieves oil with difference pressure, the hydraulic system performs protecting environment and save energy with high working efficiency.
SD7N triangle type bulldozer is an ideal machine used in desert, oil field, foresting, mining etc large earth moving program.
It can be equipped with straight tilting blade, angle blade, coal pushing blade, U shape blade; single shank ripper, three shanks ripper; ROP, FOPS, forest defense cabin etc.
Safety and comfortable operation condition, electric monitoring and ROPS cabin with reliable entire quality, excellent service is your wise choosing.
|
Item |
SD7N |
|
Operation weight (kg) |
23800 |
|
Ground pressure (kpa) |
71.9 |
|
Track gauge (mm) |
1980 |
|
Min. ground clearance (mm) |
404 |
|
Gradient |
30-25% |
|
Dozing capacity (m3) |
8.4 |
|
Blade width (mm) |
3500 |
|
Max. digging depth (mm) |
498 |
|
Overall dimensions (mm) |
7616*3500*3402 |
|
Engine brand |
Cummins/ weichai |
|
Rated revolution (rpm) |
2100 |
|
Rated power (KW) |
185 |
|
Max. torque (N.m/rpm) |
1097/1500 |
|
Rated fuel consumption (g/KW.h) |
235 |
|
Pitch (mm) |
216 |
|
Width of shoe (mm) |
560 |
