Summary
- Dimension(Long * Breadth * High):7930*3940*3549mm
- Machine Weight:37300kg
- Model Number:SD8N
- Brand Name:XCMG
- Place of Origin:Xuhzou, China
- Certification:CE
Specifications
- weight:37300.000kg
- Condition:New
- Moving Type:Crawler
- Type:High track bulldozer
- Engine:Cummins NT855-C280S10
- Power:257kw/345hp
XCMG SD8N 345hp High Track Type Dozer Bulldozer.
Engine: Cummins NTA855-C360S10
Engine Rated Power: 257 KW/345 HP
Operating weight: 32 tons & around 37 tons with ripper
Pilot joy stick: hydraulic control
Elevated sprocket, ITM track and sprockets
ROPS and air conditioned cabin, LED Lights
Semi-rigid suspended track system
SD8N high track type bulldozer is equivalent to Caterpillar Bulldozer D8R, Komatsu D155, BEML BD155 bulldozer. SD8N bulldozer can be used in road building, hydro-electric construction, mining sectors, land clearance, port development etc.
SD8N high track type bulldozer with elevated sprocket, hydraulic direct drive, semi-rigid suspended and hydraulic controls. Equipped with power separating hydraulic-mechanic type Torque converter, planetary, power shift and one lever control transmission.
SD8N bulldozer can be equipped with straight tilting blade, angle blade, coal pushing blade, U shape blade; single shank ripper, three shanks ripper; ROP, FOPS, forest defense cabin etc.
|
Specifications |
SD8N |
|
Overall size of the machine (mm) |
7930*3940*3549 |
|
Operation weight (kg) |
37300 |
|
Ground pressure (kpa) |
94 |
|
Track gauge (mm) |
2083 |
|
Blade width (mm) |
3940 |
|
The Min. ground clearance (mm) |
556 |
|
Max. digging depth (mm) |
582 |
|
Engine |
|
|
Type |
Cummins NT855-C280S10 |
|
Rated power (kW) |
257 |
|
Rated Revolution (rpm) |
2100 |
|
Undercarriage system |
|
|
type |
The track is triangle shape. / The sprocket is elevated elastic suspended |
|
Pitch (mm) |
216 |
|
Crawler width (mm) |
560 |
